RUCKUS R770 Indoor Access Point

Name: RUCKUS R770 Indoor Access Point
Brand: Classroom Tech Integrators
Availability: InStock

Get a Quote

Description

Ultra-fast, low latency wireless connections with improved capacity and efficiency

Wi-Fi 7’s extreme speed, low latency and increased capacity delivers exceptional user experiences and empowers an entirely new class of advanced connected devices and demanding applications. Need a way for wireless devices to support 8K video streams, extended reality (XR) video conferencing, massive social gaming, and more? Wi-Fi 7 is the answer and RUCKUS^® brings it to life with the R770 as the first enterprise-class AP supporting Wi-Fi 7 to hit the market.

RUCKUS Wi-Fi 7 implementation is further enhanced by RUCKUS BeamFlex+ patented smart, directional antenna technology and RUCKUS AI to optimize network performance.

Product Classification

Regional Availability	Asia \| Australia/New Zealand \| EMEA \| Latin America \| North America
Product Type	Indoor access point
Product Brand	RUCKUS^®

General Specifications

Antenna Patterns, per band	4000+
Antenna Gain	Up to 4 dBi
BeamFlex	Yes
ChannelFly	Yes
Concurrent Users	1024
Controller Support	RUCKUS One^™ \| RUCKUS SmartZone \| RUCKUS Unleashed^™ \| Standalone
Ethernet Ports	1 x 1 / 2.5 / 5 /10 GbE \| 1 x 1 GbE
IoT Support	IoT Onboard
Number of Radios	Tri-Radio
PD-MRC	Yes
PHY Rate at 2.4 GHz, maximum	689 Mb/s
PHY Rate at 5 GHz, maximum	5765 Mb/s
PHY Rate at 6 GHz, maximum	5765 Mb/s
Combined Max PHY Rate	12220 Mb/s
Radio Chains and Streams	2x2:2 (2.4 GHz) 4x4:4 (5 GHz) 2x2:2 (6 GHz)
Rx Sensitivity at 2.4 GHz	-97 dBm
Rx Sensitivity at 5 GHz	-100 dBm
Rx Sensitivity at 6 GHz	-96 dBm
SmartMesh	Yes
USB	USB 2.0
Venue Type	Education \| Hospitality \| MDU \| Manufacturing \| Office/Retail \| Public Venue
Venue Sub-Type	Convention Floor \| Lecture Hall \| Transit Stations \| Venue Common Spaces
Wi-Fi Bands Supported	2.4 GHz \| 5 GHz \| 6 GHz
Wi-Fi Generation	Wi-Fi 7
Wi-Fi Interface Standard	IEEE 802.11a/b/g/n/ac/ax/be
